Electric Water Heater AJ

The AJ Series vertical electric water heater is a reliable solution for your hot water needs. Boasting a 1500W power rating, it comes in capacities of 30L, 50L, 80L, and 100L to suit different requirements. Featuring mechanical temperature control for easy adjustment, a stainless steel heating tube for efficient heating, and optional ELCB leakage protection for safety, it ensures both convenience and security. The SPCC metal body with powder coating, polyurethane foam insulation, and blue diamond enamel liner enhance durability and heat retention. CB/CE certified, it meets high-quality standards.

Model: ADQ5

Color: White or Blue

Innovate

Authentication

Overview Features Specifications Frequently Asked Questions You May Also Like

Electric Water Heater AJ

The AJ Series vertical electric water heater stands out as a top-tier choice for residential and light commercial hot water supply. It operates at a rated power of 1500W, ensuring efficient heating. Available in capacities of 30L, 50L, 80L, and 100L, it can cater to various household sizes and usage scenarios, from small families to larger ones with higher hot water demand.

In terms of functionality, it adopts mechanical temperature control with a plug-in thermostat and bottom temperature adjustment, along with a water temperature gauge for clear temperature indication, making it simple for users to set and monitor the water temperature. The heating system utilizes a single power stainless steel heating tube; the standard is 316L stainless steel, with options for 310S/840/800 stainless steel, copper, or stainless steel enamel heating tubes to meet different performance and durability needs.

Safety is a priority, as it comes with an ordinary plug power cord, and an ELCB leakage protection power cord is optional (with plug matching based on the sales area). The build quality is excellent, with a body made of SPCC metal material with powder coating for sturdiness and corrosion resistance. An environmentally friendly polyurethane foam insulation layer, 20mm thick, effectively reduces heat loss, ensuring energy efficiency. Inside, a φ18*200mm magnesium rod and a blue diamond enamel liner (SPCC enamel) work together to prevent corrosion and extend the appliance's lifespan.

Developed according to CB/CE certification standards, the AJ Series can pass CB/CE testing, guaranteeing its compliance with international quality and safety norms. Whether for daily bathing, washing, or other hot water uses, this water heater provides a stable, efficient, and safe hot water solution.

Features

Specifications

Type	Product model	Rated Power	Functional introduction	Rated Capacity	Product size	Packaging size	Remarks
Vertical	AJ Series	1500W	1. Mechanical temperature control, plug-in thermostat, bottom temperature adjustment, water temperature gauge for the temperature indication 2. Single power, stainless steel heating tube 3. Ordinary plug power cord, optional ELCB leakage protection power cord (plug matching according to sales area) 4. Metal SPCC material with powder coating 5. Environmentally friendly polyurethane foam insulation layer, 20mm thickness 6. Built-in φ18*200mm magnesium rod 7. Blue diamond enamel liner (SPCC enamel) 8. Developed according to CB/CE certification standards, can pass CB/CE testing	30	φ380x484	445425522	1. Optional: ELCB type power cords; 2. The standard heating tube is 316L stainless steel. Optional: 310S/840/800 stainless steel, copper material, or stainless steel enamel heating tubes; 3. The carton is a regular corrugated carton; 4. Optional: 220V power 1000-3000W , 110V power 800-1500W; The quotation is for the basic configuration: 316L stainless steel heating tube, ordinary power cord, 220V/1500W power;
				50	φ380x684	445425740
				80	φ450x753	505495780
				100	φ450x893	505495920

Frequently Asked Questions

Q: How do I choose the right gas water heater capacity for my household?

A:
The capacity you need depends on the number of family members and your hot water usage patterns. For example, if you have a small family with normal hot water demand, a model with a rated hot water capacity of 12 - 16L/min (like some models in our range) might be sufficient. But for larger families or those with higher hot water consumption, such as frequent bathtub filling, you may need a model with a higher capacity, like 18 - 20L/min.
Q: What's the difference between a forced-draft and a balance-type gas water heater?

A:
A forced-draft gas water heater uses a fan to exhaust combustion gases to the outside. It requires an exhaust flue connected to the outside. In contrast, a balance-type gas water heater has a sealed combustion chamber. It draws in outside air for combustion and exhausts gases outside through a coaxial flue. This makes it safer for installation in areas with limited ventilation, as it doesn't consume indoor air for combustion.
Q: How can I ensure the safety of using a gas water heater?

A:
Our gas water heaters are equipped with multiple safety features. Most models have a “7 + 2” maximum protection system, which includes measures like over - temperature protection, anti-dry-burning protection, and flame-out protection. Additionally, features such as error warning systems and water-pressure release devices further enhance safety. Regular maintenance and inspection as per the user manual are also recommended.
Q: Can the gas water heater maintain a stable water temperature?

A:
Yes, our gas water heaters are designed with advanced temperature control technologies. For instance, micro-flame technology allows for precise adjustment of the flame, enabling accurate temperature control. Smart self-adaptation features can also adjust to changes in water pressure and gas supply, maintaining the water temperature within a narrow range, typically ±0.5℃.
Q: How energy - efficient are these gas water heaters?

A:
Our gas water heaters generally have high efficiency ratings, often exceeding 88%. Models with advanced features like condensing technology can further improve energy efficiency by recovering heat from the exhaust gases. Choosing a high-efficiency model not only saves on energy costs but also reduces environmental impact.
Q: Can the gas water heater work in low-water-pressure conditions?

A:
Some of our models are specifically designed to work in low-water-pressure environments. They have a low-water-pressure startup feature, which allows them to activate and operate normally even when the water pressure is relatively low. This ensures that you can still enjoy hot water in areas with limited water pressure.
